Airtac SAI50 Standard Cylinder SAI50AX135S
2. Piston seal features a profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Cross-reinforced aluminum barrel without tie rods ensures superior corrosion resistance. Precisely machined sensor mounting grooves enable tool-free installation;
4. Adjustable pneumatic cushioning provides smooth end-stroke deceleration;
5. Multiple cylinder configurations and mounting accessories available for versatile application requirements;
6. High-temperature resistant sealing materials accommodate operating temperatures from 0°C to 150°C.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI50
AirTAC SAI50AX135S Standard Cylinder Technical Specifications
- Model: SAI50AX135S
- Bore size: Ø50 mm
- Stroke: 135 mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Port size: M5x0.8 (G1/8 optional)
- Piston rod material: SUS304 stainless steel
- Tube material: Aluminum alloy (hard anodized)
- End cover material: Extruded aluminum
- Seal material: NBR (nitrile rubber)
- Operating temperature: -20℃ to +80℃
- Weight: 2.45 kg (±3%)
- Dimensions (L×W×H): 250mm × 60mm × 60mm (minimum extended length: 115mm)
- Mounting type: Basic front flange (ISO 15552 standard)
- Protection rating: IP65 (standard wiper included)
- Max theoretical thrust: 1570N @0.63MPa
High-precision ISO-compliant pneumatic cylinder with enhanced side load capacity, featuring wear-resistant guide bands and dual magnetic sensor slots (T-slot and U-slot compatible). The chrome-plated piston rod incorporates a multi-layer seal system for leak-free operation. Designed for 5,000km service life under standard conditions.
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- CNC machine tool door actuators
- Automotive welding fixture positioning
- Packaging machine vertical lift systems
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
before initial operation. For vertical mounting, install lock nut (accessory kit ASNU-50) to
prevent piston rod rotation. Sensor cables must use shielded wiring for EMI protection.
| Property | Property Value |
|---|---|
| sku | SAI50AX135S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | SUS420J2 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 135mm |
