Airtac SAI50 Standard Cylinder SAI50AX140
2. Piston seal features a profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Cross-reinforced aluminum barrel without tie rods ensures superior corrosion resistance. Precisely machined sensor mounting grooves enable tool-free installation;
4. Adjustable pneumatic cushioning provides smooth end-stroke deceleration;
5. Multiple cylinder configurations and mounting accessories available for versatile application requirements;
6. High-temperature resistant sealing materials accommodate operating temperatures from 0°C to 150°C.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI50
AirTAC SAI50AX140 Standard Cylinder Technical Specifications
- Model: SAI50AX140
- Type: Double-acting pneumatic cylinder
- Bore size: Ø50 mm
- Stroke: 140 mm (adjustable cushion)
- Operating pressure: 0.15-0.8 MPa
- Medium: Clean compressed air (40μm filtration required)
- Temperature range: -20℃ to +80℃
- Cushion type: Adjustable pneumatic cushion at both ends
- Port size: PT1/4 (G1/4 optional)
- Material: Aluminum alloy barrel, hard anodized
- Piston rod material: Chrome-plated carbon steel (Cr-Mo)
- Seal material: NBR (Nitrile rubber) standard
- Protection rating: IP65 (dust-tight & water jet resistant)
- Mounting style: Basic foot mounting (ISO 15552 standard)
- Weight: 2.3 kg ±5%
- Dimensions (L×W×H): 200mm × 80mm × 125mm (excluding rod)
High-performance ISO-compliant cylinder featuring precision honed tubing and corrosion-resistant construction. The SAI50AX140 combines 2.5mm thick aluminum alloy walls with triple-layer chrome plating on the piston rod for extended service life. Magnetic versions available (SAI50AX140-M9) for position sensing integration.
- Automated production line material handling
- Packaging machinery pusher mechanisms
- Automotive assembly line clamping devices
- Press machine ejection systems
- Plastic injection molding machine auxiliaries
Installation recommendations:
Maintain ≤0.3mm/m alignment tolerance during mounting. Lubricate through air port using ISO VG32 hydraulic oil.
For vertical installations, use rod-down orientation to prevent seal wear. Allow 20mm clearance for magnetic sensors.
| Property | Property Value |
|---|---|
| sku | SAI50AX140 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <140mm> |
