Airtac SAI50 Standard Cylinder SAI50AX150
$97.00
Regular price
$104.50
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAI50AX150
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO15552 (formerly ISO6431) standard cylinder
2. Piston seal features a profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Cross-reinforced aluminum barrel without tie rods ensures superior corrosion resistance. Precisely machined sensor mounting grooves enable tool-free installation;
4. Adjustable pneumatic cushioning provides smooth end-stroke deceleration;
5. Multiple cylinder configurations and mounting accessories available for versatile application requirements;
6. High-temperature resistant sealing materials accommodate operating temperatures from 0°C to 150°C.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI50
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use rod-end support brackets when stroke exceeds 300mm. Lubricate through air port
(ISO VG32 recommended) if operating in dry conditions.
2. Piston seal features a profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Cross-reinforced aluminum barrel without tie rods ensures superior corrosion resistance. Precisely machined sensor mounting grooves enable tool-free installation;
4. Adjustable pneumatic cushioning provides smooth end-stroke deceleration;
5. Multiple cylinder configurations and mounting accessories available for versatile application requirements;
6. High-temperature resistant sealing materials accommodate operating temperatures from 0°C to 150°C.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI50
AirTAC SAI50AX150 Standard Cylinder Specifications
- Model: SAI50AX150
- Bore size: 50mm (ISO 6432 standard)
- Stroke: 150mm (customizable from 25-500mm)
- Operating pressure: 0.15-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: Basic MF1 (ISO 15552 foot mounting)
- Port size: PT3/8 (G3/8 optional)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR/PU combination
- Weight: 2.3kg ±5% (without accessories)
- Dimensions:
- Length: 274mm (stroke 150mm + end caps)
- Width: 68mm (mounting foot span)
- Height: 64mm (cylinder diameter)
- Max theoretical force: 1960N @ 0.63MPa
- Speed range: 50-750mm/s (with cushion adjustment)
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Protection rating: IP65 (standard wiper seal)
High-precision ISO-compliant pneumatic cylinder featuring wear-resistant construction and dual cushioning control. The SAI50 series utilizes a chromium-plated piston rod with multi-layered sealing system for reliable operation in high-cycle applications. Extended service life of 5,000km+ under standard conditions (50mm bore models).
Typical Applications:
- Automated material handling systems
- Packaging machine pusher mechanisms
- Automotive assembly line clamping devices
- Plastic injection molding ejectors
- Food processing conveyor gate controls
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use rod-end support brackets when stroke exceeds 300mm. Lubricate through air port
(ISO VG32 recommended) if operating in dry conditions.
Critical parameters:
- Max side load: 220N @ mid-stroke
- Allowable eccentricity: ≤0.5mm
- Max piston speed with cushion: 1m/s
- Re-lubrication interval: 3 months (continuous operation)
| Property | Property Value |
|---|---|
| sku | SAI50AX150 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 150mm |
