Airtac SAI80 Standard Air Cylinder SAI80AX10
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80 Standard Cylinder SAI80AX10 Technical Specifications
- Model: SAI80AX10
- Type: ISO 6432 compliant single-acting spring return cylinder
- Bore size: 80mm (±0.1mm precision honed)
- Stroke: 10mm (Standard) ±1mm tolerance
- Operating pressure: 0.05-1.0 MPa (0.5-10 bar)
- Cushioning: Adjustable rubber buffer + shock absorber
- Mounting style: Basic type (No pre-mount accessories)
- Port size: G3/8 (BSPP thread)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Material: Aluminum alloy barrel (AlSi10Mg), Chromed steel piston rod (Cr-Mo steel, HRC 50-60)
- Weight: 2.5kg (dry, without accessories)
- Dimensions:
- Total length: 163mm (stroke 10mm)
- Barrel length: 110mm
- Rod end to base: 53mm
- Mounting center spacing: 60mm × 60mm
- Rod diameter: 25mm
- Max theoretical thrust: 502N @ 0.8MPa
- Lubrication: Pre-lubricated (Grease packed), maintenance-free for 2,000km
- IP rating: IP65 (standard wipers)
High-precision industrial cylinder with dual-cushion impact control, designed for short-stroke precision positioning. Features wear-resistant chrome plating (20-25μm thickness) and anti-rotation piston rod. The compact axial design minimizes footprint while maintaining 1,500,000 cycle durability. Requires filtered air (5-40μm) with optional auto-switch mounting grooves.
- Clamping fixtures in CNC machining centers
- High-speed sorting gates in packaging lines
- Valve actuation in chemical dosing systems
- Precision press mechanisms for electronics assembly
- Material ejection in die-casting machines
Installation notes:
- Align piston rod within 0.5° angular misalignment tolerance
- Use M6 mounting bolts (8.8 grade min) with 14-16Nm torque
- Maintain 0.5-1mm/m clearance for thermal expansion
- For vertical mounting, install rod-end down to prevent contaminant accumulation
| Property | Property Value |
|---|---|
| sku | SAI80AX10 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <10mm> |
