Airtac SAI80 Standard Air Cylinder SAI80AX1000
$378.70
Regular price
$386.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAI80AX1000
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAI80 Standard Cylinder
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate through air port using ISO VG32 hydraulic oil
during initial installation. For vertical mounting exceeding 45° angle, install auxiliary support brackets.
Critical note:
Maximum side load capacity 250N. When stroke exceeds 800mm, use guide units or stroke brackets
to prevent piston rod deflection. Cycle rate should not exceed 80% of maximum rating in continuous operation.
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80AX1000 Standard Cylinder Technical Specifications
- Model: SAI80AX1000
- Series: ISO 15552 compliant standard cylinder
- Bore size: 80 mm
- Stroke: 1000 mm (adjustable stroke available)
- Operation type: Double-acting
- Working pressure: 0.1–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Piston speed: 50–1000 mm/s
- Ambient temperature: -20℃ to +80℃
- Port size: G3/8 (NPT1/2 optional)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Mounting types: Basic type (MA1), front flange (MF1), rear clevis (MP2)
- Weight: 6.8 kg (excluding accessories)
- Dimensions: 1116mm(L) × 80mm(Bore) × 125mm(Mounting height)
- Rod end thread: M20×1.5
- Protection class: IP65 (standard), IP67 (optional)
- Optional accessories: Magnetic sensor (D-A93), rod lock, heat shield
High-performance industrial cylinder designed for heavy-duty linear motion applications. Features precision honed tubing with wear-resistant surface treatment (hard anodized) and corrosion-resistant construction. The dual piston seal design ensures stable operation under varying loads. Requires ISO 8573-1:2010 Class 3-4-3 compressed air quality.
Typical Applications:
- Automated material handling systems
- Steel mill rolling equipment
- Plastic injection molding machine ejectors
- Automotive assembly line positioning
- Packaging machinery pusher mechanisms
- Foundry equipment operation
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate through air port using ISO VG32 hydraulic oil
during initial installation. For vertical mounting exceeding 45° angle, install auxiliary support brackets.
Critical note:
Maximum side load capacity 250N. When stroke exceeds 800mm, use guide units or stroke brackets
to prevent piston rod deflection. Cycle rate should not exceed 80% of maximum rating in continuous operation.
| Property | Property Value |
|---|---|
| sku | SAI80AX1000 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <1000mm> |
