Airtac SAI80 Standard Air Cylinder SAI80AX100S
$152.57
Regular price
$160.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAI80AX100S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAI80 Standard Cylinder
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃. Avoid lateral loads exceeding 150N on piston rod.
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80 Standard Cylinder SAI80AX100S Technical Specifications
- Model: SAI80AX100S
- Type: ISO 6432 compliant single-acting spring return cylinder
- Bore size: 80 mm
- Stroke: 100 mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa (recommended 0.1–0.8 MPa)
- Temperature range: -20℃ to 80℃ (with NBR seals)
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: G3/8 (ISO 1179-1 standard)
- Piston rod thread: M20×1.5 (external)
- Material: Aluminum alloy barrel (6063-T5), hardened chromium-plated rod (45# steel)
- Seal material: Nitrile rubber (NBR) standard (FKM optional)
- Mounting: Standard foot mounting (ISO 15552 MF1), optional flange/mid-trunnion
- Protection rating: IP65 (standard wipers)
- Weight: 2.8 kg (without accessories)
- Dimensions:
- Total length (L): 318 mm (stroke 100 + base length 218)
- Body diameter (W): 95 mm (hexagonal profile)
- Height (H): 112 mm (including mounting feet)
- Rod end thread length: 30 mm
High-efficiency industrial cylinder featuring dual anti-rotation design and corrosion-resistant construction. The SAI80AX100S combines 600,000 cycle durability with 0.05 MPa ultra-low pressure start capability, making it ideal for energy-sensitive applications. Includes magnetic piston for position sensing compatibility (sensor not included).
Typical Applications:
- Automated material handling systems
- Plastic injection molding ejectors
- Food processing machinery (NBR version for oil resistance)
- Automotive assembly line clamping devices
- Textile machinery actuators
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃. Avoid lateral loads exceeding 150N on piston rod.
Performance Data:
- Theoretical output force (@0.6MPa): 3016N (extending)
- Max piston speed: 0.1–1.5 m/s
- Air consumption per cycle (@0.6MPa): 0.47 liters
| Property | Property Value |
|---|---|
| sku | SAI80AX100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
