Airtac SAI80 Standard Air Cylinder SAI80AX105
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80AX105 Standard Cylinder Technical Details
- Model: SAI80AX105
- Bore size: Ø80 mm
- Stroke: 105 mm (adjustable cushioning)
- Operating pressure: 0.05-1.0 MPa
- Operating medium: Clean air (lubricated or non-lubricated)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50-750 mm/s
- Port size: Rc1/4 (G1/4 optional)
- Mounting type: Basic type (MF1), front flange (MF2), rear flange (MF3), foot mounting (MF4)
- Piston rod material: Hard chrome-plated carbon steel
- Seal material: NBR (standard), optional Polyurethane
- Weight: 3.85 kg (excluding accessories)
- Dimensions:
- Length: 260 mm (full retracted)
- Width: 96 mm (body diameter)
- Height: 130 mm (including mounting hardware)
- ISO certification: 6431, VDMA 24562
The SAI80AX105 medium-duty industrial cylinder features enhanced side load capacity through its precision-guided piston design. Its chrome-plated stainless steel tie rods provide 20% higher rigidity than standard models, making it ideal for high-cycle applications. The dual-cushion system (front/rear adjustable) enables smooth deceleration at stroke ends, reducing impact noise by 15dB(A).
- Plastic injection molding machine ejectors
- Automotive welding fixture positioning
- Paper roll clamping in printing presses
- Packaging line product pushers
- Foundry equipment core-pulling mechanisms
Installation protocol:
For vertical mounting applications exceeding 45° angle, install external guide mechanisms.
Lubricate rod end weekly using ISO VG32 hydraulic oil when operating in dry air conditions.
Maximum side load capacity: 180N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SAI80AX105 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 105mm |
