Airtac SAI80 Standard Air Cylinder SAI80AX110
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80AX110 Standard Cylinder Technical Details
- Model: SAI80AX110
- Bore size: Ø80 mm
- Stroke: 110 mm (adjustable cushion)
- Operating pressure: 0.05–1.0 MPa
- Max thrust: 503 N @0.7 MPa
- Ambient temperature: -20℃ to +80℃
- Cushion type: Double adjustable air cushion
- Port size: G1/2 (BSPP thread)
- Piston rod thread: M20×1.5
- Mounting style: AX series (front/rear flange with integrated mounting holes)
- Material: Aluminum alloy cylinder tube, hard-anodized piston rod (SUS304 optional)
- Seal material: NBR (Nitrile rubber)
- Weight: 3.5 kg (bare cylinder), 3.8 kg with standard accessories
- Dimensions: 320mm(L) × 108mm(W) × 108mm(H) (at mid-stroke position)
- Rod end type: Female thread with pivot eye
- ISO standard: 15552 compliant
High-torque industrial cylinder with precision honed tube and wear-resistant guide bands. Features dual cushion adjustment screws for optimal end-of-stroke deceleration. Optional magnetic piston version (SAI80AX110-M9L) available for position feedback. Requires ISO VG32 hydraulic oil mist lubrication for extended seal life.
- Press machine ejection systems
- Automotive welding fixture clamping
- Plastic injection molding ejectors
- Heavy-duty conveyor gate controls
- Paper roll handling equipment
Installation guidelines:
Align cylinder axis within ±0.2° angular misalignment. Use flexible couplings for
stroke-end impact reduction. Lubricate rod weekly with Class 2 lithium grease
under high dust environments.
Critical note:
Avoid side loads exceeding 200 N. For vertical mounting, always install
rod-lock mechanism to prevent unintended descent during pressure loss.
| Property | Property Value |
|---|---|
| sku | SAI80AX110 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 110mm |
