Airtac SAI80 Standard Air Cylinder SAI80AX110S
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80AX110S Standard Cylinder Specifications
- Model: SAI80AX110S
- Bore size: 80mm
- Stroke: 110mm
- Operating pressure: 0.15–0.8 MPa
- Cushion type: Adjustable air cushion (both ends)
- Operating temperature: -20℃ to 80℃
- Port size: Rc1/4 (G1/4 optional)
- Mounting type: Basic type (MF1) with front flange & rear foot mounting holes
- Piston rod material: Hard chrome-plated steel (Cr-Mo steel base)
- Cylinder tube material: Aluminum alloy with hard anodized surface
- Seal material: NBR (standard), optional PU for high-speed applications
- Weight: 3.6kg (excluding accessories)
- Dimensions:
- Total length (L): 238mm (minimum retracted length)
- Body width (W): 110mm (mounting flange to mounting flange)
- Height (H): 80mm (excluding piston rod extension)
- Rod thread: M20×1.5 (external thread)
- Max theoretical thrust: 4016N at 0.8MPa
- ISO standard: 15552 compliant
High-precision industrial cylinder featuring wear-resistant construction and dual air cushioning for smooth operation. The SAI80 series combines heavy-duty load capacity (up to 4kN) with corrosion-resistant aluminum body, making it ideal for repetitive motion tasks. Includes magnetic piston for sensor compatibility and 360° adjustable mounting positions.
- Material handling systems (conveyor transfers)
- Press machine ejection mechanisms
- Automotive assembly line clamping devices
- Packaging machine product positioning
- Plastic injection molding machine core pulls
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5-1mm clearance between magnetic sensor and cylinder body.
Avoid lateral load exceeding 30% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | SAI80AX110S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 110mm |
