Airtac SAI80 Standard Air Cylinder SAI80AX115
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80 Standard Cylinder SAI80AX115 Technical Specifications
- Model: SAI80AX115
- Bore size: Ø80 mm
- Stroke: 115 mm (adjustable cushion)
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–800 mm/s
- Port size: G1/4 (M14×1.5 optional)
- Mounting type: Basic MF1/MF2 flange (ISO 15552 compatible)
- Cushioning: Adjustable pneumatic cushion
- Ambient temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy hard oxidation
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: NBR (Nitrile rubber)
- Weight: 3.2 kg (without accessories)
- Dimensions:
- Total length: 290 mm (at mid-stroke position)
- Body diameter: Ø90 mm
- Mounting flange: 125×40 mm
- Rod end thread: M20×1.5
- Certifications: ISO 6431, VDMA 24562
- Protection class: IP40 (dust protected)
A heavy-duty ISO-compliant pneumatic cylinder featuring precision honed tubing and double-sealed bearings. The SAI80AX115 delivers 503N thrust at 0.6MPa (extending) with ±0.5mm repeat positioning accuracy. Anti-rotation design prevents piston spin during operation. Pre-lubricated for maintenance-free operation up to 3,000km travel life.
- Press machine ejection systems
- Automotive welding fixture clamping
- Palletizing robot arm actuation
- Plastic injection molding machine gates
- Steel mill conveyor diverters
Installation guidelines:
Use M8 mounting bolts (Grade 8.8 or higher) with 22±3 N·m torque.
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, install speed controller in lower port.
| Property | Property Value |
|---|---|
| sku | SAI80AX115 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 115mm |
