Airtac SAI80 Standard Air Cylinder SAI80AX115S
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80AX115S Standard Cylinder Specifications
- Model: SAI80AX115S
- Bore size: Ø80 mm
- Stroke: 115 mm (adjustable cushion)
- Operating pressure: 0.05–1.0 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: Adjustable air cushion
- Mounting style: Basic foot + axial accessories
- Port size: G1/4 (ISO standard)
- Piston speed: 50–800 mm/s
- Rod material: Hard chrome-plated steel
- Cylinder tube: Precision honed aluminum alloy
- Seal material: NBR + PU hybrid seals
- Protection rating: IP65 (rod wiper included)
- Weight: 3.8 kg (excluding accessories)
- Dimensions:
- Extended length: 298 mm
- Retracted length: 183 mm
- Body width: 112 mm
- Mounting height: 42 mm
High-force pneumatic cylinder with dual anti-rotation guide rods, designed for heavy-duty linear motion applications. Features corrosion-resistant anodized surfaces and impact-resistant end caps. Equipped with magnetic piston for position sensing compatibility. Optional shock absorbers available for high-speed operations.
- Press machine ejection systems
- Automotive welding fixture positioning
- Palletizing robot arm actuators
- Injection molding machine clamp units
- Steel mill conveyor alignment
Installation advice:
Maintain 0.1-0.3mm alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
for initial operation. Avoid side load exceeding 15% of maximum thrust capacity.
- Thrust: 3,170 N
- Tension: 2,850 N
Service life: 5,000 km (under standard operating conditions)
| Property | Property Value |
|---|---|
| sku | SAI80AX115S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 115mm |
