Airtac SAI80 Standard Air Cylinder SAI80AX120
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80AX120 Standard Cylinder Technical Details
- Model: SAI80AX120
- Bore size: 80mm
- Stroke: 120mm
- Operation type: Double-acting
- Working pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard ISO/VDS 24552 base mount
- Port size: G1/2 (BSPP thread)
- Piston rod thread: M20×1.5
- Material: Aluminum alloy barrel, hardened chrome-plated rod
- Seal material: NBR (nitrile rubber)
- Weight: 3.8kg (without accessories)
- Dimensions: 350mm(L) × 100mm(W) × 100mm(H) (at full extension)
- Rod end type: Female thread with cushion screw
- Max theoretical force: 502N @0.5MPa (extending)
- Protection class: IP65 (rod seal area)
A heavy-duty ISO-compliant pneumatic cylinder optimized for industrial automation. Features dual adjustable air cushions for smooth deceleration and reduced impact noise. The anodized barrel surface resists corrosion in humid environments, while the triple-lip rod seal ensures minimal leakage. Requires 5-40μm filtered compressed air with lubrication (ISO VG32 recommended).
- Press machine ejection systems
- Automotive assembly line clamping
- Palletizing robot arm actuators
- Plastic injection molding machine gates
- Heavy conveyor gate controls
Installation tip:
Align cylinder axis within 0.2mm perpendicular tolerance during mounting.
For vertical installations, use M20 lock nut (order separately) to prevent
unscrewing from vibration. Lubricate rod weekly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SAI80AX120 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 120mm |
