Airtac SAI80 Standard Air Cylinder SAI80AX125
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80AX125 Standard Cylinder Specifications
- Model: SAI80AX125
- Series: ISO 15552 compliant standard cylinder
- Bore size: 80 mm
- Stroke: 125 mm (customizable 25-500 mm)
- Operating pressure: 0.15–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting types: Basic/Foot, Front Flange, Rear Flange, Double Trunnion
- Port size: 1/4" NPT (G1/4 optional)
- Temperature range: -20℃ to 80℃
- Tube material: Hard anodized aluminum alloy
- Piston rod: Chrome-plated stainless steel (Cr12MoV)
- Seals: NBR (Nitrile) standard, optional FKM/Viton
- Protection rating: IP65 (IP67 with optional wiper)
- Max thrust: 502 N @ 0.63 MPa
- Weight: 3.2 kg (without accessories)
- Dimensions: 250mm(L) × 80mm(W) × 80mm(H) (stroke-dependent length)
High-rigidity industrial cylinder with 25μm hard chrome piston rod coating for wear resistance. Features dual magnetic sensor slots (M5x0.8 thread) for position feedback. Optional shock absorber kits available for high-speed applications (>1 m/s). Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Heavy-duty press machine ejection systems
- Automotive welding fixture positioning
- Packaging line material clamping
- Foundry equipment door actuators
- Plastic injection molding machine core pulls
Installation note:
Use anti-vibration mounts when installed on equipment with >5G shock loads.
Lubricate through air port with ISO VG32 turbine oil if using non-lubricated air.
| Property | Property Value |
|---|---|
| sku | SAI80AX125 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 125mm |
