Airtac SAI80 Standard Air Cylinder SAI80AX130
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80AX130 Standard Cylinder Technical Specifications
- Model: SAI80AX130
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: 80 mm
- Stroke: 130 mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable rubber buffers (both ends)
- Piston rod diameter: 20 mm (chrome-plated steel)
- Port size: 1/4" NPT (G1/4 optional)
- Max thrust: 502 N @ 0.7 MPa (extending)
- Operating temperature: -20℃ to 80℃
- Seal material: NBR + PU combination
- Tube material: Anodized aluminum alloy
- Weight: 2.8 kg (without accessories)
- Dimensions: 250mm(L) × 90mm(W) × 90mm(H) (at mid-stroke)
- Max speed: 500-800 mm/s (lubricated operation)
- Mounting type: Basic (axial mounting accessories available)
- Protection rating: IP54 (standard seals)
High-torque industrial cylinder optimized for heavy-duty linear motion tasks. Features wear-resistant rod guides and dual sealing system (wiper seal + main seal) for contaminated environments. Compatible with auto-switch sensors (M9/M12 connectors). Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Press machine ejection systems
- Automotive welding fixture positioning
- Plastic injection molding clamp mechanisms
- Foundry equipment door actuators
- Palletizing robot end-effector drives
Installation note:
Allow 5mm minimum clearance around cylinder body for heat dissipation.
For vertical mounting, install rod end downward to prevent condensate accumulation.
Lubricate every 5,000km stroke or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | SAI80AX130 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 130mm |
