Airtac SAI80 Standard Air Cylinder SAI80AX140S
$165.13
Regular price
$172.63
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAI80AX140S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAI80 Standard Cylinder
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
Installation guidelines:
Use M12×1.75 mounting bolts (grade 8.8 or higher) with 55-60N·m torque.
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate with ISO VG32
grade hydraulic oil if operating below 0.3MPa. Avoid side load exceeding 10%
of maximum thrust capacity.
1. Compliant with ISO15552 (formerly ISO6431) standards
2. Special-profile bidirectional piston sealing structure with compact dimensions and integrated oil retention design
3. H-groove reinforced aluminum tube construction eliminates tie rods, enhances corrosion resistance. Pre-machined sensor mounting grooves enable tool-free sensor installation
4. Adjustable pneumatic cushioning ensures smooth end-of-stroke deceleration
5. Multiple bore sizes and standardized mounting accessories available for flexible system integration
6. High-temperature resistant sealing materials support operation in 0-150°C environments
Category: Standard Cylinders | Brand: AIRTAC | Series: SAI80
AirTAC SAI80AX140S Standard Cylinder Specifications
- Model: SAI80AX140S (ISO 6432 compliant)
- Bore size: 80mm
- Stroke: 140mm (customizable up to 500mm)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Port size: Rc1/4 (G1/4 optional)
- Mounting type: Basic front flange (ISO 15552 mounting interfaces)
- Piston rod material: Hard chrome-plated steel (4-6μm coating)
- Cylinder tube: Anodized aluminum alloy (12μm surface treatment)
- Seals: NBR standard (FKM available for high-temp versions)
- Weight: 3.8kg (excluding accessories)
- Dimensions:
- Extended length: 310mm ±1mm
- Retracted length: 170mm ±1mm
- Body diameter: 95mm
- Mounting hole spacing: 120mm × 120mm
- Max theoretical force: 5024N @ 1.0MPa
- Speed range: 50-750mm/s (lubricated operation)
High-precision industrial cylinder featuring dual anti-rotation guide rods for enhanced lateral load capacity (max 200N·m). The triple-seal design with integrated wiper ensures contamination resistance in ISO 18/16/13 class environments. Includes magnetic piston for position sensing compatibility.
Typical Applications:
- Automated palletizing systems (box clamping/positioning)
- Plastic injection molding machine ejectors
- CNC fixture actuation (requires shock absorber for high-cycle use)
- Automotive assembly line tooling actuators
- Heavy-duty valve operation in chemical processing
Installation guidelines:
Use M12×1.75 mounting bolts (grade 8.8 or higher) with 55-60N·m torque.
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate with ISO VG32
grade hydraulic oil if operating below 0.3MPa. Avoid side load exceeding 10%
of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | SAI80AX140S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | <140mm> |
