Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-50S
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40X100-50S Adjustable Cylinder Specifications
- Model: SAIJ40X100-50S
- Type: Double-acting adjustable stroke cylinder
- Bore diameter: 40 mm
- Stroke: 100 mm (adjustable)
- Mounting type: Front flange (MF1) with integrated guide
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: 16 mm
- Material: Aluminum alloy barrel, chrome-plated steel rod
- Cushion type: Adjustable air cushion at both ends
- Port size: Rc1/4 (G1/4 optional)
- Weight: 2.8 kg (without accessories)
- Dimensions:
- Length (retracted): 216 mm
- Width (flange base): 70 mm
- Height (including rod): 62 mm
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (DOP mist compatible)
- Protection rating: IP54 (standard seals)
A precision-engineered adjustable stroke cylinder featuring dual air cushion control and built-in guide mechanism. The SAIJ series incorporates a unique stroke adjustment mechanism with ±5mm fine-tuning capability via lockable dials. The wear-resistant guide structure minimizes lateral deflection during operation, making it ideal for applications requiring precise linear motion with variable positioning.
- Automated production line positioning systems
- Glass panel handling equipment
- PCB board press-fit mechanisms
- Packaging machine stopper adjustments
- Semiconductor wafer transfer devices
Installation note:
For optimal performance, maintain 0.5-1mm clearance between cylinder body and machine frame.
Use alignment jigs during mounting to ensure guide rail parallelism within 0.2mm/m tolerance.
- Loosen stroke lock nut (M6) using 5mm hex key
- Rotate adjustment dial (marked in 0.5mm increments)
- Test stroke with low-pressure air before full operation
- Re-tighten lock nut while maintaining dial position
| Property | Property Value |
|---|---|
| sku | SAIJ40X100-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
