Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-10
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40X1000-10 Adjustable Cylinder Specifications
- Model: SAIJ40X1000-10
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 1000mm (adjustable via mechanical stops)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-1000mm/s (lubricated condition)
- Cushioning: Adjustable hydraulic buffer at both ends
- Mounting style: Basic type (optional foot/m flange mounting)
- Rod material: Chrome-plated steel (H5 tolerance)
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination seals
- Ambient temperature: -20℃ to 80℃
- Port size: G1/8 (M5×0.8 optional)
- Weight: 8.7kg (dry, without accessories)
- Dimensions: 1220mm(L) × 50mm(W) × 50mm(H)
- Rod diameter: 16mm
- Maximum lateral load: 180N
High-precision long-stroke cylinder with 0.5mm position repeatability, featuring dual anti-rotation guides for stable linear motion. The tungsten-treated piston rod provides exceptional wear resistance in high-cycle applications (up to 5 million cycles). Integrated shock absorbers prevent end-impact damage during full-speed operation.
- Automated palletizing systems
- Large-format CNC machine tool doors
- Solar panel cleaning robot arms
- Automotive assembly line positioning jigs
- Packaging line product ejection systems
Installation guidelines:
Requires horizontal mounting with ±0.2mm/m alignment tolerance.
Lubricate with ISO VG32 hydraulic oil before initial use.
Stroke adjustment must be performed under depressurized condition.
- SAI-MD40 magnetic sensor kit
- SAI-CB40 cushion adjustment tool
- Heat-resistant seal kit (for 100℃ environments)
- Stainless steel version (SAIJ40SS series)
| Property | Property Value |
|---|---|
| sku | SAIJ40X1000-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
