Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-100
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40X1000-100 Adjustable Cylinder Specifications
- Model: SAIJ40X1000-100
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke length: 1000mm (adjustable range: 0-100mm via external stopper)
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: 16mm (chrome-plated steel)
- Cushioning: Adjustable air cushion at both ends
- Port size: G1/8 (ISO228/1 standard)
- Max thrust: 1260N @ 0.7MPa (extend), 1050N @ 0.7MPa (retract)
- Ambient temperature: -20℃ to 80℃
- Body material: Aluminum alloy (anodized surface)
- Seal material: NBR (nitrile rubber)
- Weight: 5.8kg ±3% (without accessories)
- Dimensions: 1200mm(L) × 62mm(W) × 62mm(H) (fully extended)
- Mounting type: Standard AF40 series accessories compatible
- Lubrication: Pre-lubricated (recommended relubrication every 500km travel)
High-precision long-stroke cylinder with external stroke adjustment mechanism, featuring corrosion-resistant construction and reinforced rod bearing. Designed for applications requiring precise position control in harsh environments. Includes dual magnetic sensors slots (compatible with D-A93 series sensors). Requires 5μm filtered air supply with ISO 8573-1:2010 class 4.4.3 air quality.
- Automated palletizing systems
- Plastic injection molding machine ejectors
- CNC machine tool clamping mechanisms
- Automotive assembly line positioning
- Large-scale printing press paper feed systems
Installation note:
Requires rigid mounting with alignment jigs for full stroke operation.
Maintain 0.5-1mm clearance between stopper and cylinder during adjustment.
Maximum side load: 30N at mid-stroke. For vertical installations, use rod-down orientation.
| Property | Property Value |
|---|---|
| sku | SAIJ40X1000-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
