Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-100S
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40X1000-100S Adjustable Cylinder Specifications
- Model: SAIJ40X1000-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke length: 1000mm (adjustable via mechanical stops)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Temperature range: -10℃ to 80℃
- Port size: Rc1/4 (G1/4 optional)
- Mounting style: Standard ISO 15552 foot & front flange
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP54 (standard)
- Weight: 5.8kg (including mounting accessories)
- Dimensions: 1200mm(L) × 80mm(W) × 80mm(H) (full extension)
- Rod thread: M10×1.25 external thread
- Position detection: Magnet compatible (sensor not included)
High-precision long-stroke cylinder featuring micrometer-style stroke adjustment (±0.5mm repeatability) through rotating end-lock collars. Anti-rotation design maintains piston orientation during operation. Integrated shock absorbers reduce end-impact noise by 30% compared to standard models. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Palletizing robot arm extension systems
- Automated conveyor gate actuators
- Plastic injection molding ejectors
- Solar panel tilt adjustment mechanisms
- Textile machinery tension control
Installation note:
For vertical mounting applications exceeding 500mm stroke,
add auxiliary guide rails to prevent rod deflection.
Lubricate through air line oilers monthly in high-cycle operations.
| Property | Property Value |
|---|---|
| sku | SAIJ40X1000-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
