Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-10S
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40X1000-10S Adjustable Cylinder Specifications
- Model: SAIJ40X1000-10S
- Type: ISO 15552 standard adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 1000mm (adjustable through mechanical stopper)
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Adjustable pneumatic cushion (both ends)
- Piston speed: 50–1000 mm/s
- Ambient temperature: -20℃ to +80℃
- Mounting style: Basic type (standard front flange MF1)
- Port size: M5x0.8 (G1/8 adapter optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal material: NBR (nitrile rubber)
- Weight: 3.45 kg (without accessories)
- Dimensions: 1080mm(L) × 78mm(W) × 78mm(H)
- Protection class: IP54 (standard wiper)
- Reaction force: 490N @0.5MPa
High-precision long-stroke cylinder with 360° rotatable auto-absorb mechanism, featuring dual adjustable rubber cushions for impact reduction. The "X" series design incorporates a visible stroke scale (1mm gradations) and integrated mounting slots for position sensors. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Automated material handling systems
- Plastic injection molding ejectors
- Automotive assembly line positioning
- Textile machinery tension control
- Solar panel cleaning mechanisms
Installation note:
For vertical installations exceeding 500mm stroke, use rod-end support brackets (ASU40-200 accessory recommended).
Maintain 0.3–0.6 MPa air pressure during stroke adjustment operations.
| Property | Property Value |
|---|---|
| sku | SAIJ40X1000-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
