Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-20
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40X1000-20 Adjustable Cylinder Specifications
- Model: SAIJ40X1000-20
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø40mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.05–0.8 MPa
- Cushioning type: Adjustable rubber buffer (both ends)
- Port size: Rc1/4 (NPT1/4 optional)
- Mounting style: Basic type (MF1) with multiple mounting options via accessory kits
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel
- End caps: Die-cast aluminum
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃
- Weight: 9.2kg ±3% (without accessories)
- Dimensions:
- Length: 1080mm (minimum retracted length)
- Width: 56mm (mounting flange width)
- Height: 56mm (cylinder outer diameter)
- Protection rating: IP65 (standard), IP67 (optional wiper upgrade)
- Lubrication: Pre-lubricated (DOP-free grease)
High-precision adjustable stroke cylinder with dual-position locking mechanism for mid-stroke positioning. Features chromium-plated piston rod with anti-rotation design and multi-layer sealing system. The extended stroke adjustment scale (graduated in 1mm increments) enables micron-level positioning accuracy when combined with external stoppers. Designed for heavy-duty cycles with 5,000km+ service life under standard conditions.
- Long-stroke press machines (book binding, leather processing)
- Automated warehouse stacker cranes
- Solar panel cleaning robot actuators
- Automotive welding fixture positioning
- Glass tempering furnace door mechanisms
Installation note:
Requires minimum 0.5mm/m alignment tolerance. Use only with filtered air (5μm+40μm dual-stage filtration recommended).
For vertical installations exceeding 45° angle, specify optional guide rod kit SAJG-40X to prevent piston rod deflection.
| Property | Property Value |
|---|---|
| sku | SAIJ40X1000-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
