Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-20S
$163.27
Regular price
$170.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAIJ40X1000-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAIJ40 Adjustable Cylinder
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
Installation protocol:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical installations exceeding 500mm stroke,
use auxiliary rod support brackets (sold separately). Lubricate guide shafts every 500km of cumulative travel.
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40 Adjustable Cylinder SAIJ40X1000-20S Technical Details
- Model Code: SAIJ40X1000-20S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø40mm (±0.2mm tolerance)
- Stroke length: 1000mm (adjustable in 1mm increments)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: 20S-type front flange with integrated mounting grooves
- Rod end thread: M16×1.5 male thread (ISO 228 standard)
- Port size: G1/8 (BSPP) with 7mm push-in fittings
- Piston rod material: Chrome-plated carbon steel (2-3μm coating)
- Tube material: Anodized aluminum alloy (6063-T5)
- Seal type: NBR seals with wear-resistant guide rings
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Weight: 6.8kg (without accessories)
- Dimensions: 1120mm(L) × 82mm(W) × 82mm(H)
- ISO standard: 15552 compliant (formerly ISO 6431)
High-precision long-stroke cylinder featuring mechanical stroke adjustment locks with position indicators. The 20S mounting variant includes reinforced flange brackets for horizontal heavy-load applications. Requires 5μm filtered lubricated air (ISO 8573-1 class 4.4.2) with recommended ISO VG32 hydraulic oil mist lubrication.
Industrial Applications:
- Automated palletizing systems (box positioning)
- Plastic injection molding ejector mechanisms
- Automotive welding fixture positioners
- Paper converting machine tension control
- Solar panel production line alignment
Installation protocol:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical installations exceeding 500mm stroke,
use auxiliary rod support brackets (sold separately). Lubricate guide shafts every 500km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | SAIJ40X1000-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
