Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-30
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40 Adjustable Cylinder SAIJ40X1000-30 Technical Details
- Model: SAIJ40X1000-30
- Type: ISO 15552 standard adjustable stroke cylinder
- Bore size: 40mm (1-9/16")
- Stroke length: 1000mm (adjustable through external stoppers)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: FA-40 series front flange (standard), optional rear pivot
- Rod end: M20×1.5 male thread
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Port size: G1/8 (NPT1/8 optional)
- Temperature range: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Weight: 6.8 kg (with 1000mm stroke)
- Dimensions: 135mm(W) × 135mm(H) × 1255mm(L) (full extension)
- Seal material: NBR standard (FKM available for high-temp)
- Protection rating: IP54 (standard wiper design)
High-precision long-stroke cylinder featuring external stroke adjustment via mechanical stoppers. The anodized barrel resists corrosion in humid environments, while the double-sealed piston design ensures stable operation in 24/7 industrial applications. Includes magnetic piston for position sensing compatibility.
- Automated palletizing systems requiring variable stacking heights
- Plastic injection molding machine ejectors
- Automotive assembly line positioning fixtures
- Packaging machine pusher mechanisms
- Textile machinery tension control systems
Installation note:
For maximum stability with 1000mm stroke, support rod end with MGJ40 series guide mechanism.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃. Avoid side load exceeding 50N.
| Property | Property Value |
|---|---|
| sku | SAIJ40X1000-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
