Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-50
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40 Adjustable Cylinder SAIJ40X1000-50 Specifications
- Model: SAIJ40X1000-50
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable hydraulic buffer
- Mounting style: Basic type (MF1)
- Port size: 1/4" (G1/4)
- Operating temperature: -20℃ to 80℃
- Material: Aluminum alloy body, NBR seals
- Weight: 3.8 kg (bare cylinder), 4.2 kg (with accessories)
- Dimensions: 1100mm(L) × 50mm(W) × 50mm(H) (full extension)
- Rod thread: M10×1.25 (ISO standard)
- Max thrust: 490 N @ 0.6 MPa
- Speed range: 50–800 mm/s
- Protection rating: IP54 (standard)
High-precision long-stroke cylinder with unique position-locking mechanism for millimeter-level positioning accuracy. Features dual chrome-plated piston rod (hardness HRC 45-50) and wear-resistant guide rings. Includes magnetic piston for position feedback compatibility. Designed for applications requiring precise stroke adjustment without disassembly.
- Automated production line positioning systems
- Sheet metal bending machine stroke control
- Plastic injection molding ejector mechanisms
- Automotive assembly jig positioning
- Textile machinery tension control systems
Installation notes:
- Align cylinder axis within ±0.2° deviation
- Use flexible couplings for stroke >500mm
- Lubricate with ISO VG32 hydraulic oil (do not mix greases)
- Allow 20mm clearance for magnetic sensor installation
| Property | Property Value |
|---|---|
| sku | SAIJ40X1000-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
