Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-50S
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40 Adjustable Cylinder SAIJ40X1000-50S Specifications
- Model: SAIJ40X1000-50S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø40mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard foot mounting (MF1) with adjustable stopper
- Operating temperature: -20℃ to 80℃
- Port size: Rc1/4 (G1/4 optional)
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: NBR + Polyurethane
- Weight: 5.2kg ±3% (without accessories)
- Dimensions:
- Extended length: 1050mm (stroke 1000mm + end caps)
- Body diameter: Ø50mm
- Mounting base: 80mm × 40mm
- Rod end thread: M16×1.5
Heavy-duty adjustable stroke cylinder with precision positioning capability, featuring a unique dual-lock stroke adjustment mechanism for millimeter-level positioning accuracy. The hardened piston rod and triple-lip seal design ensure 3,000km+ service life under full load. Includes shock-absorbing bumpers and anti-rotation guide for high-moment applications.
- Palletizing robot end-effector positioning
- Automated warehouse vertical lift systems
- Sheet metal bending machine backgauges
- Plastic injection molding ejector mechanisms
- Solar panel array alignment systems
Installation note:
Maximum side load 150N. Requires rigid mounting surface with flatness ≤0.1mm/100mm.
Lubricate with ISO VG32 hydraulic oil before initial use. Stroke adjustment must be performed
at ≤0.3MPa pressure.
| Property | Property Value |
|---|---|
| sku | SAIJ40X1000-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
