Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-75S
$163.27
Regular price
$170.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAIJ40X1000-75S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAIJ40 Adjustable Cylinder
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
Installation guidelines:
For strokes over 500mm, use intermediate support brackets (AIR-AC40 recommended)
to prevent rod deflection. Maintain 0.5-1mm/m alignment tolerance during mounting.
1. ISO15552 (formerly ISO6431) compliant standard cylinder
2. Features asymmetric bidirectional sealing structure with integrated oil reservoir functionality for compact dimensions and enhanced lubrication retention
3. Reinforced cross-section aluminum alloy tube (non-tie-rod design) with superior corrosion resistance. Integrated sensor mounting grooves enable rapid magnetic switch installation
4. Equipped with smoothly adjustable cushioning mechanism for stable stroke termination
5. Multiple specifications available with comprehensive selection of cylinder accessories and mounting configurations
6. High-temperature resistant sealing materials extend operational range to 0~150℃
Category: Standard Cylinders | Brand: AirTAC | Series: SAIJ40
AirTAC SAIJ40 Adjustable Cylinder SAIJ40X1000-75S Technical Specifications
- Model Code: SAIJ40X1000-75S
- Bore Size: 40mm (ISO 6432 standard)
- Stroke Length: 1000mm (adjustable with stopper mechanism)
- Buffer Type: 75° adjustable pneumatic cushion (dual-side)
- Operating Pressure: 0.05–1.0 MPa
- Temperature Range: -20℃ to 80℃ (dry air required below 0℃)
- Port Size: Rc1/8 (NPT1/8 optional)
- Mounting Style: Basic type (MSUB40 bracket compatible)
- Piston Rod Diameter: 16mm (chrome-plated steel)
- Tube Material: Aluminum alloy (hard anodized)
- Seal Material: NBR + PU combination
- Max Theoretical Thrust: 125.6N @ 0.63MPa
- Max Speed: 500mm/s (with cushion engaged)
- Weight: 4.2kg ±3% (without accessories)
- Dimensions: 1160mm(L) × 56mm(W) × 56mm(H) (full extension)
- Protection Class: IP54 (standard wipers)
- ISO Certification: 6432/DIN ISO 15552 compliant
High-precision long-stroke cylinder featuring micrometer-style stroke adjustment (±5mm fine tuning) through its rotating end cap. The 75S variant includes enhanced cushioning with 4-stage damping control, making it ideal for heavy payload deceleration. Requires 5μm filtered air and monthly lubrication cycle for optimal performance.
Industrial Applications:
- Automated palletizing systems
- Sheet metal bending machine tool changers
- Plastic injection molding ejectors
- Solar panel cleaning robot actuators
- Automotive assembly line positioning
Installation guidelines:
For strokes over 500mm, use intermediate support brackets (AIR-AC40 recommended)
to prevent rod deflection. Maintain 0.5-1mm/m alignment tolerance during mounting.
Service Advisory:
Replace rod wipers every 500,000 cycles in high particulate environments.
Use ISO VG32 hydraulic oil for lubrication. Avoid angular loads exceeding ±2°.
| Property | Property Value |
|---|---|
| sku | SAIJ40X1000-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
