Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X10-10
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X10-10 Adjustable Cylinder Specifications
- Model: SAIJ63X10-10
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63 mm
- Stroke: 10 mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable (both ends)
- Mounting style: Basic type (other options available)
- Port size: M5×0.8 (standard), G1/8 optional
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 1.95 kg ±3%
- Dimensions (L×W×H): 200mm × 63mm × 63mm (at mid-stroke)
- Rod end thread: M10×1.25
- Maximum speed: 500 mm/s
- Lubrication: Pre-lubricated (relubrication interval: 2000 km)
Precision-adjustable compact cylinder featuring micrometer-style stroke adjustment mechanism with ±0.5mm repeatability. The dual-cushion design minimizes end-impact noise while maintaining positioning accuracy. Anodized surfaces provide corrosion resistance for humid environments. Includes magnetic piston for position sensing compatibility.
- Precision clamping fixtures in CNC machining centers
- Micro-positioning in semiconductor handling systems
- Pressure regulation in plastic injection molding gates
- Sheet metal bending machine stroke control
- Pharmaceutical blister packaging alignment
Installation note:
Use locknuts (not included) for stroke adjustment fixation. Maintain 0.5-1mm play in mounting brackets for thermal expansion. For vertical mounting, install rod end downward to prevent particle accumulation.
- Loosen locknut with 8mm wrench
- Rotate adjustment screw (1 full turn = 1.25mm stroke change)
- Lock position while maintaining rod alignment
- Perform 3-5 test cycles before production use
| Property | Property Value |
|---|---|
| sku | SAIJ63X10-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | <10mm> |
