Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-10
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X100-10 Adjustable Cylinder Specifications
- Model: SAIJ63X100-10
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63 mm
- Stroke: 100 mm (adjustable through external stopper)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable hydraulic shock absorber
- Mounting type: Standard ISO 15552 foot & flange mounts
- Port size: G1/8 (M5 optional via adapter)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile) with wear-resistant ring
- Operating temperature: -10℃ to 80℃
- Weight: 2.4 kg ±3% (including mounting accessories)
- Dimensions:
- Extended length: 281 mm
- Retracted length: 181 mm
- Body diameter: 80 mm
- Mounting hole spacing: 60×60 mm
- Protection class: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (recommended relube interval: 1,000 km)
High-precision adjustable stroke cylinder with mechanical position locking, featuring a unique dual-cushion system (air cushion + hydraulic absorber) for ultra-smooth end-of-stroke deceleration. The hardened stainless steel guide bushing ensures precise rod alignment, while the external stroke adjustment mechanism allows ±5mm fine-tuning without disassembly. Compatible with all ISO 15552 mounting accessories.
- Precision press-fit operations in automotive assembly
- Variable height positioning in packaging machinery
- Semiconductor wafer handling robots
- Adjustable clamping fixtures for CNC machining
- Food processing equipment (corrosion-resistant version available)
Installation tip:
Always engage at least 75% of the adjustable stopper thread length during stroke setting.
Use locknut with 1.5-2 N·m torque after adjustment. Lubricate sliding surfaces monthly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
