Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-100
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X100-100 Adjustable Cylinder Specifications
- Model: SAIJ63X100-100
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: Rc1/4 (G1/4 optional)
- Operating temperature: -10℃ to 80℃
- Piston rod material: Chrome-plated carbon steel
- Tube material: Aluminum alloy (anodized)
- Seal material: NBR/PU (oil and heat resistant)
- Weight: 2.8 kg ±3%
- Dimensions (L×W×H): 226mm × 63mm × 63mm (extended length: 326mm)
- Protection rating: IP54 (standard), IP67 (optional)
- Mounting types: Standard MF1 front flange, optional rear pivot
High-precision industrial cylinder featuring stroke adjustment mechanism with ±5mm micro-positioning capability. The dual-axis design allows external stroke adjustment via locknuts without disassembly. Integrated wear indicators on rod seals enable predictive maintenance. Compatible with auto-switch sensors (M9/M12 connectors).
- Precision clamping in CNC fixture systems
- Variable stroke material handling robots
- Packaging machine ejector mechanisms
- Plastic injection molding ejectors
- Automated test equipment positioning
Installation note:
For optimal performance, lubricate through air port (ISO VG32 recommended) before initial use.
Adjust cushioning screws in 1/4-turn increments during operation. Avoid side load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
