Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-100S
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63 Adjustable Cylinder SAIJ63X100-100S Technical Specifications
- Model: SAIJ63X100-100S
- Bore size: Ø63 mm
- Stroke: 100 mm (adjustable)
- Operation type: Double-acting
- Working pressure: 0.1–0.9 MPa
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange mount (ISO 15552 standard)
- Port size: 1/4" NPT (G1/8 optional)
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile butadiene rubber)
- Temperature range: -20℃ to +80℃
- Lubrication: Required (ISO VG32 turbine oil recommended)
- Weight: 2.8 kg ±3%
- Dimensions (L×W×H): 300mm × 82mm × 82mm (extended length)
- Repeat positioning accuracy: ±0.5 mm
- Protection class: IP40 (standard)
The SAIJ63X100-100S features micro-adjustable stroke control via mechanical stoppers, with dual pneumatic cushions to minimize end-impact noise. Its chrome-plated piston rod and wear-resistant seals enable 3,000km+ service life under standard conditions. The cylinder body incorporates debris-resistant wiper rings and auto-lubrication grooves.
- Precision press-fit operations in automotive assembly
- Variable height positioning in packaging machinery
- Clamping force adjustment in CNC fixtures
- Material handling systems requiring stroke modification
- Plastic injection molding ejector mechanisms
Installation tip:
Align within 0.2mm perpendicularity tolerance during mounting.
For vertical installations, use rod-end support brackets when stroke exceeds 150mm.
Lubricate through air supply (oil mist type) at 1 drop/m³ airflow.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
