Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-20S
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X100-20S Adjustable Stroke Air Cylinder Specifications
- Model: SAIJ63X100-20S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 63mm
- Stroke length: 100mm (adjustable through external stopper)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Rubber bumper + adjustable hydraulic shock absorber
- Mounting style: Standard ISO/VDS 24552 foot mounting (optional flange/bracket)
- Port size: G1/4 (NPT1/4 optional)
- Operating temperature: -10℃ to 80℃
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR/PU compound
- Weight: 2.8kg (including mounting hardware)
- Dimensions:
- Extended length: 276mm
- Retracted length: 176mm
- Body width: 80mm
- Mounting height: 63mm
- ISO standard: 15552 (VDMA 24552)
- Protection rating: IP54 (standard seals)
Precision-engineered adjustable stroke cylinder featuring micro-positioning capability through its external mechanical stopper. The dual cushioning system minimizes end-impact noise while maintaining positioning accuracy (±0.2mm repeatability). Corrosion-resistant construction with 20μm hard chrome plating on piston rod ensures durability in humid environments.
- Packaging line product positioning gates
- CNC machine tool clamping mechanisms
- Automated welding fixture height adjustment
- Printing press paper feed systems
- Robotic arm end-effector positioning
Installation tip:
For optimal performance, align the adjustment stopper perpendicular to the cylinder axis and lubricate with ISO VG32 hydraulic oil during initial setup. Allow 5mm clearance around the stopper mechanism for maintenance access.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
