Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-30S
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X100-30S Adjustable Cylinder Specifications
- Model: SAIJ63X100-30S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63 mm
- Stroke: 100 mm (adjustable via mechanical stopper)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -10℃ to 80℃
- Port size: 1/4" NPT (G1/8 optional)
- Cushion type: Adjustable rubber cushion (both ends)
- Mounting style: Standard ISO 15552 foot & front flange
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 2.85 kg (without accessories)
- Dimensions:
- Extended length: 290 mm
- Retracted length: 190 mm
- Body diameter: 80 mm
- Rod end thread: M16×1.5
- ISO certification: ISO 6432 compliant
- Protection rating: IP54 (standard seals)
High-precision adjustable stroke cylinder with dual-position memory function, featuring a patented anti-rotation mechanism for stable linear motion. The hardened piston rod and triple-lip seal design ensure 5,000km service life under rated load. Includes magnetic piston for sensor compatibility and auto-lubricating bushings for maintenance-free operation.
- Precision positioning in semiconductor handling equipment
- Variable height adjustment for automotive assembly jigs
- Packaging machine stopper mechanisms
- Press-fit operations in electronic component assembly
- Modular conveyor system actuators
Installation note:
Requires periodic lubrication (every 5 million cycles) with ISO VG32 hydraulic oil.
Adjust stroke while depressurized using hex key on both end caps. Maximum side load
capacity: 150N at mid-stroke. Avoid rapid pressure changes above 0.6 MPa.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
