Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-40
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X100-40 Adjustable Stroke Air Cylinder Specifications
- Model: SAIJ63X100-40
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63mm
- Stroke: 100mm (adjustable through stopper mechanism)
- Operating pressure: 0.15-1.0 MPa
- Cushioning type: Adjustable air cushion at both ends
- Mounting style: Standard MF1 (front flange) & MB1 (rear foot)
- Port size: Rc1/4 (NPT1/4 optional)
- Operating temperature: -20℃ to 80℃
- Piston rod material: Chrome-plated steel
- Cylinder tube material: Aluminum alloy with hard anodization
- Seal material: NBR (Nitrile rubber)
- Weight: 2.8kg (excluding accessories)
- Dimensions: 200mm(L) × 63mm(W) × 75mm(H) (at mid-stroke position)
- Rod thread: M16×1.5
- Maximum speed: 500mm/s
- Lubrication: Non-lube (pre-lubricated) or oil mist compatible
Precision-adjustable pneumatic cylinder featuring dual cushion control and position-locking capability. The stroke adjustment mechanism allows ±2mm micro-positioning through rotating end stoppers. Hard chrome-plated piston rod resists side loads up to 15% of maximum thrust. Integrated mounting grooves enable multi-angle sensor installation for position feedback.
- Precision press-fit operations in assembly lines
- Variable height positioning in material handling
- Tooling fixture clamping with adjustable force
- Packaging machine product height compensation
- Automated welding equipment positioners
Installation note:
Lock adjustment screws with 2.5N·m torque after positioning.
Maintain 0.5mm minimum clearance between stopper and cylinder head during adjustment.
Use C-shaped wrench (included) for stroke calibration.
Avoid full extension/retraction during adjustment.
Always depressurize before stroke modification.
Maximum side load capacity reduces by 30% when used in vertical orientation.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
