Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-40S
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X100-40S Adjustable Cylinder Specifications
- Model: SAIJ63X100-40S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63mm
- Stroke: 100mm (adjustable)
- Mounting style: MA-type (adjustable cushion)
- Operating pressure: 0.1-0.8 MPa
- Cushioning type: Adjustable pneumatic cushion
- Port size: PT1/4 (G1/4 optional)
- Temperature range: -20℃ to 80℃
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy with oxidation treatment
- Seal material: NBR (Nitrile rubber)
- Weight: 2.5kg ±5%
- Dimensions (L×W×H): 200×80×100mm (at mid-stroke position)
- Max piston speed: 500-750 mm/s
- Lubrication: Pre-lubricated (Daphne Alpha 3 compatible)
- Protection rating: IP54 (standard wiper seal)
Precision-adjustable cylinder featuring dual cushion control with ±5% stroke adjustment capability. The hexagonal rod design prevents rotation during operation, while the corrosion-resistant coating ensures durability in humid environments. Requires filtered air (5-50μm) with 1-10 mg/m³ oil mist lubrication.
- Precision press-fit operations in electronics assembly
- Variable height positioning in packaging machinery
- Clamping force adjustment systems
- Automated material handling with variable stroke requirements
- Plastic injection molding ejector mechanisms
Installation note:
For optimal performance, maintain 0.3-0.5mm alignment tolerance during mounting.
Always perform cushion adjustment at 80% of maximum operating pressure.
Recommended maintenance interval: 2,000km stroke distance or 6 months.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
