Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-50
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63 Adjustable Cylinder SAIJ63X100-50 Technical Specifications
- Model Code: SAIJ63X100-50
- Type: Compact adjustable stroke cylinder (double acting)
- Bore size: Ø63 mm (ISO 6432 standard)
- Stroke: 100 mm (±0.5mm tolerance)
- Adjustment range: 50% of total stroke (50mm via external stopper)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable rubber buffers at both ends
- Port size: Rc1/4 (G1/4 optional)
- Piston speed: 50-700 mm/s (lubricated)
- Ambient temperature: -20℃ to 80℃
- Seal material: Polyurethane (NBR optional)
- Rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Weight: 1.65 kg (without accessories)
- Dimensions: 230mm(L) × 80mm(W) × 80mm(H) (fully extended)
- Mounting options: Basic type (no foot) with multiple accessory brackets available
- ISO certification: 6432/DIN ISO 15552 compliant
Precision stroke-adjustable cylinder featuring a dual-position locking mechanism with visual stroke indicators. The SAIJ63 series incorporates wear-resistant rod seals and an anti-rotation guide design, making it ideal for applications requiring mid-stroke positioning accuracy. Requires air filtration of 5μm or finer.
- PCB board clamping systems with variable thickness
- Automated packaging line product height adjustment
- Glass panel polishing equipment pressure control
- Automotive welding fixture positioning
- Pharmaceutical blister packaging depth regulation
Installation recommendation:
For optimal performance, maintain 0.5-1mm clearance between stopper and cylinder end during adjustment.
Lubricate with ISO VG32 hydraulic oil when operating below -10℃.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
