Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-50S
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X100-50S Adjustable Cylinder Specifications
- Model: SAIJ63X100-50S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 63 mm
- Stroke: 100 mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–1000 mm/s
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Mounting type: Front flange with tapped holes (ISO 15552 standard)
- Port size: G1/8 (BSPP thread)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃
- Weight: 2.8 kg (with standard accessories)
- Dimensions:
- Extended length: 250 mm
- Retracted length: 150 mm
- Body diameter: 80 mm
- Mounting flange width: 50 mm
High-precision industrial cylinder featuring stepless stroke adjustment through mechanical stops, ideal for applications requiring variable positioning. The dual adjustable cushioning system minimizes impact noise and vibration at stroke ends. Corrosion-resistant construction with IP65 protection rating ensures reliability in harsh environments.
- Automated assembly line positioning systems
- Plastic injection molding machine ejectors
- Automotive welding fixture clamping
- Packaging machine product height adjustment
- Semiconductor handling equipment
Installation note:
Lubricate through air port using ISO VG32 hydraulic oil before initial operation.
For stroke adjustment: Loosen lock nut (M8) and rotate adjustment screw (max. ±5mm from nominal stroke).
Maintain minimum 15mm clearance around cylinder body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
