Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-75
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X100-75 Adjustable Cylinder Technical Details
- Model Code: SAIJ63X100-75
- Cylinder Type: Double-acting with external stroke adjustment
- Bore Size: Ø63 mm
- Stroke Length: 100 mm (adjustable via mechanical stops)
- Operating Pressure: 0.05–1.0 MPa
- Piston Speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer + external shock absorber
- Port Thread: G3/8 (BSPP) dual ports
- Ambient Temp Range: -20℃ to +80℃
- Piston Rod Material: Chrome-plated carbon steel (S45C)
- Tube Material: Anodized aluminum alloy
- Seal Type: HNBR seals (high-temp variant available)
- Mounting Options: AF3 flange, MP4 square mount, or basic foot mounting
- Weight: 2.8 kg (without accessories)
- Dimensions: 230mm(L) × 85mm(W) × 85mm(H) (fully extended)
- ISO Standard: 15552 compliant
High-precision adjustable stroke cylinder featuring dual-stage position locking and overstroke protection. The SAIJ63 series incorporates a unique 360° rotatable cushioning adjustment knob with torque limiter (75N·m max), allowing fine-tuning of end position damping without disassembly. Anti-rotation guide slots ensure stable linear motion under side loads up to 120N.
- Variable position clamping in CNC fixture systems
- Packaging line product ejection with force control
- Plastic injection molding machine core-pull mechanisms
- Automated warehouse stacker positioning
- Glass tempering furnace door actuators
Adjustment Protocol:
Always depressurize before rotating the yellow adjustment collar. For optimal performance:
1) Back off adjustment screws fully before initial operation
2) Gradually tighten while testing stroke endpoints
3) Lock with 13mm counter nut after calibration
Maintenance cycle: Relubricate every 500,000 cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
