Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X100-75S
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63 Adjustable Stroke Cylinder SAIJ63X100-75S Technical Details
- Model Code: SAIJ63X100-75S
- Bore Size: 63mm (ISO standard)
- Stroke: 100mm (max), adjustable 20-75mm via mechanical stopper
- Adjustment Range: 75mm (indicated by "-75" suffix)
- Operating Pressure: 0.1-0.9 MPa
- Temperature Range: -20℃ to +80℃
- Cushioning Type: Adjustable rubber buffer (both ends)
- Mounting Style: Basic foot or flange mounting (accessories sold separately)
- Port Size: G1/8 (BSPP thread)
- Piston Rod Material: Hard chrome-plated steel
- Tube Material: Anodized aluminum alloy
- Seal Material: NBR (Nitrile rubber) standard
- Weight: 2.8kg ±3% (without accessories)
- Dimensions:
- Total Length (extended): ~300mm
- Body Diameter: 80mm
- Mounting Base: 120mm × 60mm
- Rod Thread: M16×1.5
Heavy-duty adjustable stroke cylinder with precision positioning capability, featuring dual-axis mechanical stroke adjustment screws for millimeter-level accuracy. The anodized body resists corrosion in humid environments, while the triple-lip rod seal ensures minimal leakage. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Packaging line product height compensation systems
- Die-casting machine ejector mechanisms
- Automated welding fixture positioning
- Textile machinery tension control
- Semiconductor wafer handling robots
Operational Advice:
Lock adjustment screws with 2.5N·m torque after positioning.
Perform stroke calibration every 50,000 cycles. Avoid side-load
forces exceeding 150N to prevent rod deflection.
| Property | Property Value |
|---|---|
| sku | SAIJ63X100-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
