Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X1000-10
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63 Adjustable Cylinder SAIJ63X1000-10 Technical Details
- Model: SAIJ63X1000-10
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63 mm
- Stroke length: 1000 mm (adjustable)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Standard MF1 (front flange) with adjustable rear support
- Port size: 1/4" NPT (M5 optional)
- Piston rod thread: M20×1.5
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, Chrome-plated steel rod
- Seal material: NBR (Nitrile rubber)
- Weight: 6.8 kg (±2%)
- Dimensions: 1145mm(L) × 80mm(W) × 80mm(H) (at full extension)
- Rod end type: Female threaded with spherical bearing
- Maximum speed: 500 mm/s
- Lubrication: Pre-lubricated (Relubrication interval: 3000 km)
High-precision long-stroke cylinder with position-lock mechanism (patented SAIJ design), featuring dual-axis adjustable mounting points and corrosion-resistant coating. The T-slot design on barrel surface allows easy sensor mounting. Includes built-in shock absorbers for high-speed operations up to 0.8 MPa. Requires 40μm filtered air with ISO VG32 hydraulic oil mist lubrication.
- Automated assembly line positioning systems
- Large-format CNC machine tool clamping
- Packaging machinery with variable product sizes
- Automotive welding fixture adjustments
- Lumber processing equipment actuators
Installation advice:
Use rigid mounting brackets for horizontal installations over 800mm stroke.
Apply lateral support every 500mm for vertical applications. Maintain 0.5-1mm
alignment tolerance between rod end and load connection.
Critical note:
Avoid full stroke operation for first 50 cycles. Perform break-in procedure
at 0.3 MPa with 50% stroke length to seat seals properly.
| Property | Property Value |
|---|---|
| sku | SAIJ63X1000-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
