Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X1000-10S
$231.93
Regular price
$239.43
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAIJ63X1000-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAIJ63 Adjustable Cylinder
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
Installation guidance:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical installations exceeding 500mm stroke,
use external guide mechanisms. Lubricate rod weekly with ISO VG32 oil in high-cycling (>500cpm) applications.
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63 Adjustable Cylinder SAIJ63X1000-10S Technical Specifications
- Model Code: SAIJ63X1000-10S
- Bore Size: Ø63mm (ISO 6432 standard)
- Stroke: 1000mm (adjustable with ±3mm precision)
- Operating Pressure: 0.05–1.0 MPa
- Piston Speed: 50–800 mm/s (lubricated condition)
- Cushioning Type: Adjustable elastic buffer (both ends)
- Mounting Style: Standard MF1 front flange + rear foot (ISO 15552)
- Rod Thread: M20×1.5 external (10mm rod diameter)
- Port Size: G1/8 (NPT1/8 optional)
- Seal Material: NBR (Nitrile rubber)
- Temperature Range: -20℃ to +80℃
- Ambient Humidity: ≤95% RH (non-condensing)
- Weight: 5.2kg (aluminum body with steel rod)
- Dimensions: 1165mm(L) × 80mm(W) × 80mm(H)
- Repeat Positioning Accuracy: ±0.5mm
- IP Rating: IP54 (standard dust/moisture protection)
High-precision long-stroke cylinder featuring dual-axis adjustable stroke mechanism with locking nuts. The SAIJ63 series incorporates wear-resistant chromium-plated piston rod and low-friction seals, optimized for high-cycle applications. Requires ISO VG32 hydraulic oil mist lubrication (0.3–0.5cm³/min recommended).
Typical Applications:
- Automated palletizing systems (box positioning)
- Plastic injection molding machine ejectors
- Textile machinery tension control units
- Automotive welding fixture positioning
- Paper converting equipment feed mechanisms
Installation guidance:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical installations exceeding 500mm stroke,
use external guide mechanisms. Lubricate rod weekly with ISO VG32 oil in high-cycling (>500cpm) applications.
Stroke Adjustment:
- Loosen both lock nuts (M12) using 19mm wrench
- Rotate end cover (clockwise to shorten stroke)
- Re-tighten nuts to 18–22Nm torque
- Perform 3–5 test cycles before operation
| Property | Property Value |
|---|---|
| sku | SAIJ63X1000-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
