Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X1000-20
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63 Adjustable Cylinder SAIJ63X1000-20 Technical Details
- Model Code: SAIJ63X1000-20
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63mm
- Stroke length: 1000mm (adjustable through built-in stopper)
- Operating pressure: 0.1–0.9 MPa
- Piston rod thread: M20×1.5
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1) with optional foot/m flange
- Ambient temperature: -20℃ to +80℃
- Seal material: Nitrile rubber (NBR) standard
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Weight: 5.8kg (excluding mounting accessories)
- Dimensions: 1125mm(L) × 63mm(W) × 63mm(H) (at full extension)
- Port size: G1/8 (M5 adaptor available)
- Max piston speed: 500–700 mm/s
- Repeat positioning accuracy: ±0.5mm
High-precision long-stroke cylinder with external stroke adjustment mechanism, featuring corrosion-resistant aluminum alloy construction and chrome-plated piston rod. The dual cushioning system minimizes end-impact noise, while the magnetic piston version (add "-M" suffix) enables position feedback. Requires 40μm filtered air and regular lubrication for optimal performance.
- Automated assembly line positioning systems
- Packaging machinery with variable product sizes
- Automotive welding fixture clamping
- Textile machinery thread tension control
- Warehouse stacking robots requiring long reach
Installation tip:
Maintain 0.5–1mm alignment tolerance during mounting. For vertical installations,
use the anti-drop nut (optional accessory SAJ-M6) to prevent piston rod sagging.
Allow 150mm clearance at stroke ends for cushion adjustment.
| Property | Property Value |
|---|---|
| sku | SAIJ63X1000-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
