Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X1000-20S
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X1000-20S Adjustable Cylinder Specifications
- Model: SAIJ63X1000-20S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63mm (±0.1mm tolerance)
- Stroke: 1000mm (manually adjustable in 1mm increments)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: G1/4 (ISO standard)
- Piston speed: 50–800 mm/s (lubricated operation)
- Ambient temperature: -10℃ to 80℃
- Mounting style: Basic type (standard) with optional MF1/MF2/MB mounts
- Rod end: External thread M20×1.5
- Weight: 6.8kg (without accessories)
- Dimensions: 1085mm(L) × 85mm(W) × 85mm(H)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal type: HNBR seals (oil & heat resistant)
- Repeat accuracy: ±0.5mm
High-precision industrial cylinder designed for long-stroke applications requiring position flexibility. Features dual micro-adjustment screws (M6×1) for precise stroke calibration and anti-rotation guide mechanism. Includes magnetic piston for sensor compatibility. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Automated pallet stacking systems
- Press machine stroke control
- Textile machinery tension adjustment
- Solar panel positioning mechanisms
- Woodworking CNC feed control
Installation tip:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use auxiliary support brackets every 600mm. Pre-lubricate with AirTAC P-1 Grease
before initial operation.
| Property | Property Value |
|---|---|
| sku | SAIJ63X1000-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
