Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X1000-30
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X1000-30 Adjustable Cylinder Technical Details
- Model: SAIJ63X1000-30
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63mm (±0.1mm tolerance)
- Stroke length: 1000mm (adjustable in 1mm increments)
- Operating pressure: 0.15–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston speed: 50–800 mm/s (lubricated condition)
- Ambient temperature: -20℃ to +80℃
- Mounting type: Standard ISO 15552 (preferred) or custom brackets
- Rod end thread: M20×1.5 (external)
- Seal material: Nitrile-butadiene rubber (NBR) with wear-resistant ring
- Weight: 8.6 kg (without accessories)
- Dimensions: 1185mm(L) × 80mm(W) × 80mm(H) (fully extended)
- Port size: G1/4 (ISO 228 standard)
- Rod diameter: Ø20mm (chrome-plated steel)
- Repeat positioning accuracy: ±0.5mm
High-precision long-stroke cylinder with position feedback capability through optional magnetic piston. Features dual adjustable air cushions for smooth deceleration and impact reduction. The anodized aluminum tube body with corrosion-resistant coating ensures durability in harsh environments. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Automated material handling systems (palletizers/conveyors)
- Press brake tool positioning in metal fabrication
- Plastic injection molding machine ejectors
- Automotive assembly line clamping fixtures
- Packaging machine product positioning gates
Installation guidelines:
Maintain 0.5mm minimum alignment tolerance during mounting.
Use flexible couplings for stroke lengths above 500mm.
Recommended maintenance: Relubricate every 500km of cumulative travel distance.
| Property | Property Value |
|---|---|
| sku | SAIJ63X1000-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
