Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X1000-30S
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X1000-30S Adjustable Cylinder Specifications
- Model: SAIJ63X1000-30S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63mm (ISO 6432 standard)
- Stroke: 1000mm (adjustable via mechanical stopper)
- Operating pressure: 0.1–0.9 MPa
- Operating medium: Dry air (lubricated or non-lubricated)
- Cushioning: Adjustable pneumatic cushioning at both ends
- Ambient temperature: -20℃ to +80℃
- Piston speed: 50–800 mm/s
- Port thread: G3/8 (NPT1/4 optional)
- Rod end thread: M20×1.5 (external)
- Mounting type: FA-type front flange (ISO 15552)
- Seal material: NBR + Polyurethane
- Protection class: IP54 (standard wiper)
- Weight: 18.7 kg (with standard accessories)
- Dimensions: 1165mm(L) × 85mm(W) × 85mm(H)
- Repeat positioning accuracy: ±0.5mm
- Sensor compatibility: Built-in magnet for cylinder position sensors
High-precision long-stroke cylinder with stroke adjustment mechanism, featuring anodized aluminum barrel and chrome-plated piston rod. The 30S variant includes reinforced mounting flange and oversized cushioning adjustment screws for high-moment applications. Requires air filtration ≤5μm with oil mist lubrication recommended for extended seal life.
- Automated palletizing systems with variable stack heights
- Plastic injection molding machine ejectors
- Paper converting equipment with adjustable cutting lengths
- Automotive welding fixture positioning
- Heavy-duty conveyor gate actuators
Installation note:
Support rod end with linear bearing when stroke exceeds 800mm.
Adjust cushioning valves gradually (1/4 turn increments) under motion.
| Property | Property Value |
|---|---|
| sku | SAIJ63X1000-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
