Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X1000-40S
$231.93
Regular price
$239.43
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAIJ63X1000-40S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAIJ63 Adjustable Cylinder
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
Installation note:
Maintain parallel alignment during mounting - maximum allowable angular misalignment ≤0.2mm/m.
For horizontal installations exceeding 800mm stroke, recommend using intermediate rod supports.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air supply.
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63 Adjustable Cylinder SAIJ63X1000-40S Specifications
- Model: SAIJ63X1000-40S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63 mm
- Stroke: 1000 mm (adjustable through stopper mechanism)
- Adjustment range: 0-100% of stroke
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable elastic cushion at both ends
- Port size: Rc1/4 (G1/4 optional)
- Mounting type: Standard MF1 front flange & rear square flange
- Ambient temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Rod material: SUS304 stainless steel
- Seal type: NBR rubber (standard), optional PU seals
- Weight: 6.8 kg (with standard accessories)
- Dimensions: 1250mm(L) × 80mm(W) × 80mm(H) (full extension)
- Rod thread: M12×1.75 male thread
- Max theoretical thrust: 1414N @0.5MPa
- ISO standard: 15552 compliant
High-precision long-stroke cylinder featuring a unique dual-position locking mechanism for mid-stroke stopping capability. The hardened piston rod and triple-lip seal design ensure reliable operation in high-cycle applications. Includes magnetic piston for position sensing compatibility.
Typical Applications:
- Automated material handling systems requiring variable stroke control
- Packaging machinery for adjustable product positioning
- Automotive assembly line tooling fixtures
- Textile machinery with dynamic stroke requirements
- Large-format printing equipment carriage movement
Installation note:
Maintain parallel alignment during mounting - maximum allowable angular misalignment ≤0.2mm/m.
For horizontal installations exceeding 800mm stroke, recommend using intermediate rod supports.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air supply.
| Property | Property Value |
|---|---|
| sku | SAIJ63X1000-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
