Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X1000-50
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63 Adjustable Cylinder SAIJ63X1000-50 Technical Details
- Model: SAIJ63X1000-50
- Type: Double-acting adjustable stroke cylinder
- Bore size: 63mm (±0.1mm tolerance)
- Stroke: 1000mm (adjustable through mechanical stopper)
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Port size: PT1/4 (G1/4 optional)
- Piston rod material: Chrome-plated steel (Cr-Mo alloy)
- Tube material: Anodized aluminum alloy (6063-T5)
- Seal type: Nitrile rubber (NBR) with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Max speed: 500–800 mm/s (with cushion engaged)
- Weight: 4.8 kg (dry weight, ±3% tolerance)
- Dimensions: 1165mm(L) × 80mm(W) × 80mm(H) (extended length)
- Retracted length: 165mm (excluding mounting accessories)
- Rod thread: M16×1.5 (external)
- Mounting options: Basic type (MF1), front flange (MF2), rear clevis (MF4)
- Sensor compatibility: Built-in magnet for inductive proximity switches
High-precision industrial cylinder with micrometer-style stroke adjustment mechanism (±0.5mm repeat accuracy). Features triple sealing system with wiper seal, main seal, and buffer seal for contamination resistance. The chrome-plated piston rod undergoes salt spray testing for 96hrs minimum. Includes adjustable cushioning screws with locknuts for precise deceleration control.
- Automated palletizing systems requiring long-stroke precision
- Plastic injection molding machine ejectors
- Automotive assembly line positioning devices
- Packaging machine product pushers
- CNC machine tool clamping mechanisms
Maintenance note:
Lubricate with ISO VG32 hydraulic oil (1-2 drops per port weekly).
Avoid lateral loading exceeding 30N·m. For vertical installations,
use tandem cylinders or external guides for stability.
| Property | Property Value |
|---|---|
| sku | SAIJ63X1000-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
