Airtac SAUJ100 Adjustable Cylinder SAUJ100X100-10
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100 Adjustable Cylinder SAUJ100X100-10 Technical Details
- Model Code: SAUJ100X100-10
- Cylinder Type: Double-acting adjustable stroke
- Bore Size: Ø100mm
- Stroke: 100mm (mechanically adjustable)
- Operating Pressure: 0.05–1.0 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting Style: Square flange (ISO 15552 standard)
- Port Size: G3/8 (NPT1/4 optional)
- Piston Rod Thread: M20×1.5
- Weight: 5.8kg ±2%
- Dimensions (L×W×H): 325mm × 125mm × 125mm (extended length)
- Material: Aluminum alloy body, chrome-plated steel rod
- Seal Type: HNBR with wear-resistant ring
- Protection Class: IP54 (standard), IP67 optional
- Optional Accessories: Magnetic sensor (D-A93), guide kit
Heavy-duty adjustable stroke cylinder featuring dual-position mechanical locking mechanism for precise stroke control. The hardened piston rod and triple-layer sealing system ensure reliable performance in high-cycle applications. Includes rotation-prevention guide slots and maintenance-free lubrication design.
- Press machine die height adjustment systems
- Automated welding fixture positioning
- Palletizing robot end-effector control
- Injection molding ejector mechanisms
- Agricultural equipment height adjustment
Installation Guidelines:
Use M8 grade 8.8 mounting bolts with Loctite 243. Maintain 0.5mm minimum
alignment tolerance between cylinder and load path. Lubricate with ISO VG32
hydraulic oil during initial installation. Perform stroke calibration after
every 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | SAUJ100X100-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
