Airtac SAUJ100 Adjustable Cylinder SAUJ100X100-100
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100X100-100 Adjustable Cylinder Specifications
- Model: SAUJ100X100-100
- Type: Double-acting adjustable stroke cylinder
- Bore size: 100mm
- Stroke: 100mm (adjustable range: 0-100mm)
- Operating pressure: 0.15–0.8 MPa
- Port size: G1/2 (ISO228 standard)
- Cushioning: Adjustable rubber buffer
- Mounting type: Square flange (ISO/VDMA compatible)
- Cylinder tube material: Hard anodized aluminum alloy
- Piston rod material: Chrome-plated carbon steel (Cr-Mo)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 3.8kg (excluding accessories)
- Dimensions: 300mm(L) × 100mm(W) × 100mm(H) (at full extension)
- Rod end thread: M20×1.5
- Max thrust: 628N @0.5MPa
- Lubrication: Pre-lubricated (Oil-free operation possible)
Industrial-grade adjustable stroke cylinder featuring precision-machined components and dual-position locking mechanism. The SAUJ series incorporates a unique stroke adjustment collar with 1mm graduation marks for precise positioning. Anti-rotation design ensures stable linear motion, while the double-lip rod seal minimizes leakage. Compatible with ISO 15552 mounting accessories.
- Variable height work platforms in assembly lines
- Clamping force adjustment in CNC fixture systems
- Material handling with variable stacking heights
- Packaging machine stopper positioning
- Automotive welding jig positioning
Installation note:
Always lock adjustment collar with 3Nm torque after positioning. Use alignment jig (PN: SAUJ-AL100)
during mounting to prevent side load. Lubricate through air port using ISO VG32 pneumatic oil if
operating in high-cycle applications (>500 cycles/min).
- Inspect rod seals every 500,000 cycles
- Re-lubrication interval: 6 months (continuous use)
- Max permissible rod end play: ±0.5mm
| Property | Property Value |
|---|---|
| sku | SAUJ100X100-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
