Airtac SAUJ100 Adjustable Cylinder SAUJ100X100-100S
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100X100-100S Adjustable Stroke Cylinder Specifications
- Model: SAUJ100X100-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø100mm
- Stroke: 100mm
- Adjustment range: 0-100mm (continuous positioning)
- Operating pressure: 0.05-0.9 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Port size: G1/2
- Mounting style: Standard MF series bracket
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy cylinder tube, CR12MOV piston rod
- Seal material: NBR (nitrile rubber)
- Weight: ~3.8kg (excluding accessories)
- Dimensions: 320mm(L) × 130mm(W) × 135mm(H) (fully extended)
Industrial-grade adjustable cylinder featuring a unique mechanical lock mechanism for precise stroke control. The chrome-plated piston rod with wear-resistant coating ensures extended service life in high-cycle applications. Integrated shock absorbers minimize end-impact noise by 40% compared to standard models.
- Precision press machine stroke adjustment
- Automated material handling systems
- Variable height work platforms
- Plastic injection molding ejectors
- Automotive assembly line positioning
- Packaging machine product height adaptation
Installation note:
Always align cylinder axis with motion direction within ±0.5° tolerance.
Apply silicone-based lubricant (ISO VG32) monthly for optimal seal performance.
Maximum side load capacity: 150N at mid-stroke position.
| Property | Property Value |
|---|---|
| sku | SAUJ100X100-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
