Airtac SAUJ100 Adjustable Cylinder SAUJ100X100-10S
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100X100-10S Adjustable Cylinder Specifications
- Full model: SAUJ100X100-10S
- Bore size: Ø100mm
- Stroke: 100mm (adjustable through built-in stroke limiter)
- Operating pressure: 0.1-0.9 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1) with front flange
- Port size: G3/8 (BSPP thread)
- Piston speed: 50-750 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: Nitrile rubber (NBR) standard
- Rod material: Chrome-plated carbon steel
- Weight: 2.85 kg (dry, without accessories)
- Dimensions: 200mm(L) × 100mm(W) × 100mm(H) (retracted position)
- Rod thread: M16×1.5 external thread
- ISO standard: 15552 compliant
Heavy-duty adjustable stroke cylinder with precision position locking mechanism, featuring dual adjustable cushioning for smooth deceleration. The wear-resistant design incorporates a chromium carbide-coated rod guide for extended service life in high-cycle applications. Includes magnetic piston for sensor compatibility.
- Press machine stroke control systems
- Automated welding fixture positioning
- Plastic injection molding ejectors
- Conveyor gate actuators
- Die casting machine core pullers
Installation note:
Lubricate rod with ISO VG32 hydraulic oil before initial operation.
Allow 15mm clearance around cushion adjustment screws for maintenance access.
Use locknuts (not included) for fixed stroke applications.
| Property | Property Value |
|---|---|
| sku | SAUJ100X100-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
